Siemens SINAMICS G120

  • rebeccavanessendel
  • 7 days ago
  • 2 min read
ree


The Modular Multifunctional Frequency Converter


The modular structure of the components and the wide power range from 0.55 to 250 kW ensure that the user is always able to assemble the ideal converter for individual applications and industry branche.


This series of converters is available in three voltage variants for connection to 200 V, 400 V, and 690 V networks. In addition, the Siemens SINAMICS G120 features a comprehensive machine safety package. SINAMICS Startdrive is used for commissioning the safety functions.


Multifunctional. Combinable. Safe.

ree

Multifunctional


  • Wide power range from 0.55 kW to 250 kW

  • Versatile drive system for the most diverse applications and industry branches

  • Available not only in low and medium, but also in high-voltage versions

ree


Combinable


  • Host of component combination options (Power Module, Control Unit, operator panel)

  • Simple connection to electric motors and control systems into an existing system and automation landscape

  • With Totally Integrated Automation (TIA Portal) and SINAMICS Startdrive - one standard engineering for all drives

ree

Safe


  • Machine safety with Safety Integrated

  • Safety functions: STO, SS1, SBC, SLS, SDI, SSM

  • Seamless implementation of safety functions in accordance with SIL 2 (EN 61508) and PL d (EN ISO 13849-1)



The modular SINAMICS G120 converter system comprises the Power Module, the Control Unit, and an optional operator panel


The Control Unit controls and monitors the Power Module and the connected motor using multiple selectable closed-loop control types. It supports communication with a local or central controller and monitoring devices. The Power Module supplies the motor in a power range from 0.37 kW to 250 kW. It features state-of-the-art IGBT technology with pulse width modulation for extremely reliable and flexible motor operation. Comprehensive protection functions provide a high level of protection for the Power Module and the motor.


Suitable Applications for SINAMICS G120

  • Pumping / ventilating / compressing: The modular frequency converter is suitable for the following applications.

  • Moving: SINAMICS is the drive for simple as well as highly dynamic conveyor systems and stacker cranes.

  • Processing: SINAMICS is the drive for continuous process with high speed and torque accuracy.

  • Positioning: SINAMICS is the drive for the positioning of individual or multiple coordinated axes.


Power-Flo Technologies is proud to partner with Siemens and their SINAMICS G120 that delivers a powerful combination of flexibility, safety, and efficiency, making it an ideal solution for a wide range of industries and applications. Its modular design, broad power range, and seamless integration with TIA Portal ensure easy customization and reliable performance. With advanced safety functions and robust motor protection, the G120 not only maximizes operational reliability but also enhances productivity. Whether for pumping, moving, processing, or positioning, this converter system provides the versatility and confidence needed for modern automation challenges.
